Ely Retreat Home

Explore this Ely cabin exclusively on our virtual tour, September 19–October 4. Full-access or virtual-only ticket required. Tickets will go on sale in early August.

Project Type: New Build

After years of vacationing in Ely, the owners’ deep appreciation for the rugged beauty of Lake Shagawa inspired the creation of their modest, four-season, waterfront retreat designed for reflection, creativity, and connection to the landscape. Drawing from the simplicity of the region's traditional cabins, the home consists of two compact structures: a primary living space and a detached garage/art studio, both long, slender black volumes that recede into the surrounding trees. Together, these forms establish a quiet presence and reinforce a retreat into nature.

The home’s linear form is oriented parallel to the lake, ensuring every room captures views of the water or forest while taking advantage of soft northern light. Along the lakefront side, the cabin’s roof extends outward to create a deck with deep overhangs and wing walls that frame views while offering refuge from weather and privacy from neighbors.

The placement of the structures was guided by a deep respect for the landscape, minimizing disturbance and preserving the character of the site. Disturbed areas were restored with native plantings to return the property to its natural state. Careful siting also protects views and allows the structure to feel embedded in the landscape rather than imposed.

Performance and restraint shape the design as much as the landscape. The compact footprint and high-performance triple-pane glazing create an efficient envelope that balances energy use with carefully framed views. Radiant in-floor heating and efficient mechanical systems complement passive strategies to maintain comfort year-round.

Inside, a restrained palette of recycled basswood, gypsum, and reclaimed flooring creates a calm, tactile environment that defers to the surrounding forest and lake, an atmosphere perfectly suited to creative contemplation.

As the owner describes, “Being away from the screen lets my mind wander… Drawing at the cabin expands my vocabulary.” The result is a quiet, enduring retreat that supports both daily living and creative exploration while remaining deeply attuned to its setting.

AIA Framework for Design Excellence: Design for Ecosystems, Energy, Economy, and Resources

Design for Ecosystems: The siting of the cabin and garage/studio was guided by a deep respect for the existing landscape. Placement carefully avoided disturbing mature pines and moss-covered boulders, and although the property’s setback allowed the cabin to be closer to the water, the architect chose a more recessed position to minimize site disruption and preserve the towering trees. With a focus on keeping design interventions as light touches on the site, no manicured lawns or ornamental plantings were introduced; instead, all disturbed areas were restored with native plantings and trees, allowing the site to return seamlessly to its natural state.

Design for Energy: The compact building footprint and low window-to-wall ratio creates a highly efficient envelope that balances performance with connection to the landscape. Strategically located, minimal windows on the east, south and west facades provide glimpses of the wooded site, while limiting solar heat gain and providing privacy to the road and adjacent lots. To the north, expansive windows prioritize views of the lake, and a 6’ overhang with side walls offers shade, privacy, and a wind break. The use of high-performance windows and doors with triple-pane glazing and UPVC mullions significantly reduces energy loss at these openings. Tilt-turn doors double as windows for fresh air ventilation and cooling in the bedrooms and living spaces. Radiant in-floor heat and minimal HVAC systems supplement the passive strategies when needed to enhance occupant comfort and the cabin’s overall thermal performance.

Design for Economy & Resources: The 16-foot main structural height and width of the cabin was designed in close collaboration with the contractor to maximize efficiency while reducing construction labor, waste, and cost, ultimately decreasing the carbon footprint of the home. From the earliest stages, the dimensions of the cabin were informed by standard stock lumber sizes. This approach minimized on-site cutting of structural members—an essential consideration given the short building season. For durability and longevity, a simple yet resilient metal siding was chosen, ensuring the cabin will withstand the elements with minimal maintenance. Economical materials including basswood and gypsum were used to clad the interior walls and ceilings, while the flooring was sourced from remnants of other projects.
